LED DOWNLIGHT SERIES

COB Recessed Spot LED Downlight

A family of recessed COB spot downlights with several reflector shapes, cutout sizes and beam options. The series is intended for focused indoor lighting where buyers need model selection and coordinated finishes.

Key Features

Models SF-DH02-T01 through T07 plus SF-DT03-C100
12W to 15W wattage options
Multiple 38°, 40°, 60° and 90° beam configurations
Selectable 3000K to 6000K CCT
Black and white with black finish options

Pricing is quoted according to the selected model, specification and order quantity.

SPECIFICATIONS

Available Models and Specifications

Models & Electrical

Models: SF-DH02-T01 to T07, SF-DT03-C100
Wattage: 12W / 13W / 15W
Input: AC200-240V, 50/60Hz
Power factor: ≥0.9
Dimming: Triac

Light Output

LED: COB
CCT: 3000K / 4000K / 5000K / 6000K
CRI: ≥80
Lumens: 800-1500lm, model dependent
Beam angles: 38° / 40° / 60° / 90° by model

Dimensions & Housing

Diameter: Approximately 100-110mm
Cutout: 80mm / 85mm / 90mm / 95mm
Height: Approximately 90-95mm
Material: Aluminum
IP rating: IP20 or IP40 by model

APPLICATIONS & PACKAGING

Plan the Complete Order

Application Scenarios

Suitable for retail stores, hotels, restaurants, galleries, showrooms and other indoor commercial spaces requiring more focused light distribution than a wide-beam downlight.

Packaging Information

Standard unit box and export carton are available. Quantity per carton varies by model. Custom logo, label, color box and shipping marks can be quoted after the model mix is confirmed.

OEM & ODM OPTIONS
